Thông tin chi tiết sản phẩm:
|
| Phong cách: | có thể tùy chỉnh | Phạm vi nhiệt độ: | -20 ° C đến 120 ° C. |
|---|---|---|---|
| Ủng hộ: | Tùy chỉnh không chuẩn | Nguồn gốc: | Trung Quốc |
| Niêm phong: | Fkm | Bảo hành: | Bơm nước |
| Thời gian dẫn đầu: | Vận chuyển nhanh chóng | Người mẫu: | BIA |
| dấu vết: | YUEMI |
| Model | d(mm) | d3 | d7 | l1 | l3 |
| YM BIA-14 | 14 | 27.0 | 30 | 23.7 | 5.0 |
| YM BIA-16 | 16 | 28.5 | 32 | 26.0 | 5.0 |
| YM BIA-18 | 18 | 30.5 | 35 | 30.0 | 7.5 |
| YM BIA-20 | 20 | 34.0 | 35 | 29.0 | 8.0 |
| YM BIA-25 | 25 | 39.0 | 40 | 33.5 | 8.0 |
| YM BIA-28 | 28 | 42.0 | 43 | 33.5 | 8.0 |
| YM BIA-30 | 30 | 44.0 | 45 | 34.5 | 9.0 |
| YM BIA-32 | 32 | 47.0 | 48 | 42.5 | 9.0 |
| YM BIA-33 | 33 | 47.0 | 48 | 42.5 | 9.0 |
| YM BIA-35 | 35 | 49.0 | 50 | 42.5 | 9.0 |
| YM BIA-38 | 38 | 54.0 | 56 | 42.5 | 9.0 |
| YM BIA-40 | 40 | 56.0 | 58 | 42.5 | 9.0 |
| YM BIA-43 | 43 | 59.0 | 61 | 46.0 | 9.5 |
| YM BIA-45 | 45 | 62.0 | 63 | 47.5 | 9.5 |
| YM BIA-48 | 48 | 64.0 | 66 | 47.5 | 9.5 |
| YM BIA-50 | 50 | 66.0 | 70 | 47.5 | 9.5 |
| YM BIA-53 | 53 | 69.0 | 73 | 50.5 | 9.5 |
| YM BIA-55 | 55 | 72.0 | 75 | 50.5 | 9.5 |
| YM BIA-58 | 58 | 80.0 | 78 | 51.5 | 9.5 |
| YM BIA-60 | 60 | 80.0 | 80 | 51.5 | 9.5 |
| YM BIA-70 | 70 | 90.0 | 92 | 56.0 | 11.0 |
Performance Capabilities:
|
Temperature
|
-30ºC to 200ºC, dependent on the elastomer
|
|
Pressure
|
≤1.0MPa |
|
Speed
|
≤10m/s |
|
End play/axial float allowance
|
±0.1mm
|
|
Size
|
14-70MM
|
|
Brand
|
YUEMI
|
|
Face
|
Carbon, SiC, TC
|
|
Seat
|
Ceramic, SiC, TC
|
|
Elastomer
|
NBR, EPDM
|
|
Spring
|
SS304
|
|
Metal parts
|
SS304
|
|
Idividual Packing
|
Using foam and plastic paper wrapped, then put one piece of seal in one box,finally put in standard export carton.
|
If the seal is not the one you need, contact us and inform us your pump model or drawing, material, shaft size for quotation. We will advise you and offer you corresponding mechanical seals.
Customized products and OEM is welcomed.
We offer factory price, high quality, fast delivery and best services.
